Home /Products/Gas Pressure Sintering Furnace/Lab Equipment Industrial Automatic Sinter 1400c Vacuum Box Atmosphere Degreasing Furnace

Lab Equipment Industrial Automatic Sinter 1400c Vacuum Box Atmosphere Degreasing Furnace

1.0 Pieces
MOQ
Lab Equipment Industrial Automatic Sinter 1400c Vacuum Box Atmosphere Degreasing Furnace
Features Gallery Product Description Request A Quote
Features
Specifications
Classification: Laboratory Heating Equipments
Model Number: SYN-JZ-V1400X
Usage: Heating Treatment
Temperature Control: 51 Segments Programmable
Heating Element: SiC Heating Rod
Heating Rate: ≤20 ℃ /min
Max Temperature(℃): 1400C
Power(KW): 2.5
Type: Tube Furnace
Application: Lab Equipment
Voltage: AC:220 ; 50/60Hz
Furnace Structure: Double Layer Steel Casing With Air Cooling
Basic Infomation
Model Number: SYN-JZ-V1400X
Payment & Shipping Terms
Packaging Details: Industrial 1400c Automatic Degreasing Sintering Vacuum Box Atmosphere Furnace Inside: Wrapped by PE paper Mid : Filled with Poly-foam. Outside: Packed in wooden box
Supply Ability: 150 Set/Sets per Year
Product Description
Products Description
Introduction：
JZ-V1400X facilitate operation of firing cycles where atmosphere condition can be altered during operation cycle, from oxidizing,(such as air to inert atmosphere), or argon/nitrogen to rough vacuum.This type of furnace makes multi-atmosphere process in one cycle possible: binder burn out in air and parts sintering under vacuum or inert gas atmosphere.
These furnaces are designed for accurate air/inert gas flow rate control, accurate temperature control, excellent temperature
uniformity, long lasting performance and safe operations.
It is ideal for laboratories and small scale production for temperatures up to 1400℃.

Application：
This type of furnace is widely used for heating treatment of materials in vacuum, recursive, protective atmosphere, also can be
used for heating treatment of special materials. The furnace chamber is ceramic fiber with excellent thermal insulation;

Features：
1: Top quality heating elements doesn't pollute the heating sample.
2: Better temperature uniformity and better thermal insulation.
3. Power control with 51 segments programmable.
4. S type high accuracy thermocouple.
5. Vacuum system and gas flow control system.
6. High purity alumina ceramic fiber chamber.
Specification



Inside Chamber Size & material
4" x 4" x 5" (101*101*127mm)
 6" x 6" x 6" (152*152*152mm)
8" x 8" x 8" (203*203*203mm)
Voltage
10" x10" x12" (254*254*304mm)
12" x 12" x 16" (304*304*406mm)
18" x 18" x 18" (457*457*457mm)
Tube materials
24" x 24" x 24" (609*609*609mm)
Temperature in air and argon gas
1400°C
Temperature in vacuum
1300°C
Temperature Control
PID automatic control via SCR (Silicon Controlled Rectifier) power control, e. g. current limiting phase angle fired the resistor with 51 programmable segments.
Temperature Accuracy
+/- 1°C
Heating Element
U type SiC
Thermocouple
S Type
Working Voltage
AC 208V-240V single phase, 50/60 Hz (100A air breaker is required)
Max. Power
3kw-50kw
Warranty
One year limited warranty (Consumable parts such as processing tubes, o-rings and heating elements are not covered by the warranty)
Details Images
OUR SERVICE
1.Timely response
Timely response to your inquiry, multiple choice recommendations based on your demand, quickly respond mails and provide solutions.
2. Strict quality control
Arrange production on time and control quality strictly.
3. Shorter delivery time
Book the earliest vessel or plane to guarantee the delivery time.
4.Professional Services
Provide exclusive and unique solution according to our experience
Provide customized design according to our customers' requirements
Provide all the detailed news and pictures from order to delivery
Provide the most reasonable logistics for customers to save every penny
Offer relative export documents and original certificate if needed
5.After-Sales Service
Train how to install the machine, train how to use the machine
Engineers available to service machinery overseas.
Relanted Products
Our Company
Henan Synthe Corporation was founded in January 2013, as a separate and independent company to better serve its customers. SYNTHE was engaged in the design, development, manufacture, and sales of high-temperature insulation, vacuum-formed ceramic fiber heaters, diffusion heaters, and high-quality thermal processing equipment, all custom designed to meet your thermal requirements. Our products are used around the world in the most demanding heat treatment, lab thermal furnaces, dental, photovoltaic solar, semiconductor and environmental protection applications, temperature ranges from room temperature 20°C ( 68°F) to 1800°C ( 3272°F). For over ten years in the industry, we have been a problem-solver working with our customers to resolve their thermal management problems.
Product packaging
Packing：
In order to ensure the customer receive the furnace and accessories without any damage, we packed the furnace in three layers.
First, the furnace is wrapped by clear plastic paper, then filled the gap by polyfoam. Finally, it is packed by wooden box.
Shipping：
1.By courier, like DHL,UPS,FEDEX,etc. it usually takes 3-4 days to arrive.
2.By air to the air port, it usually takes 5-7 days to arrive.
3.By sea to sea port, it usually takes 15-30 days to arrive.
4.If your delivery time is very urgent, we suggest you to choose by courier or by air.
5.If it not very urgent,we will suggest you to choose by sea,it is very cheap.
FAQ
1.Is your company accepting customization?
We have our own factory and excellent technical team, and we accept OEM service.

2.We are not professional for operation and installation of your machine?
While it is not a stumbling block,our machine is easy to operate, no need to be professional,and the instruction manual and video sent to you are enough.What's more,we have professional engineers and they can solve all questions.

3. Which shipment is available?
By sea, by air , by express or as your requirement.

4.Do you inspect the finished products?
Yes,each step of production and finished products will be carried out inspection by QC department before shipping.
