vacuum arc furnace Small Lab Electric Atmosphere Vacuum Furnace for Sintering
factory price of 1700.C vacuum atmosphere sintering muffle furnace
1700 Degree Atmosphere Vacuum Muffle Furnace
1600-1700 Degree high temperature atmosphere laboratory vacuum electric muffle furnace
SH-1700T vacuum atmosphere furnace is our new product through long research and improvement. LCD touch screen, more easy to set the temperature program. It integrate the heating system, mixing gas system, vacuum system, circulating cooling system, monitoring system. The machine with multi-functions can meet the most requirement of customers.
1. SH - 1700T with double-shell structure and equipped with air cooling system, ensure the furnace surface have a low temperature, operation more safety.
2. Furnace chamber adopted imported alumina polycrystalline fibers material, with good insulation properties and more energy saving, Heating elements adopted Silicon molybdenum rod and depending on the working atmosphere plating different protective coating on the heating element, greatly improved the heating element servicing life.
3. The inner furnace chamber adopts high temperature resistant alloy materials, professional vacuum design, unique sealing technology, ensures no gas leak, vacuum degree more higher than our competitors’ similar products.
4. Reserved gases inlet interface, can be individually control the gas flow; equipped with mixing gas device, can working with different protective gas, satisfy atmosphere experiment requirements;
5.Over-temperature alarm and power cut-off automatically, leakage protection, safe and reliable operation.
Widely used in universities, research institutions, industrial and mining enterprises to do high temperature sintering atmosphere, atmosphere restoring and vacuum annealing.
Type | SH-1200T | SH--1400T | SH-1700T |
Chamber Size | 250*250*300mm | ||
Max temperature | 1200℃ | 1400℃ | 1700℃ |
Working temperature | 1100℃ | 1300℃ | 1600℃ |
Heating Rate | 0~20℃/min | 0~20℃/min | 0~20℃/min |
Temperature accuracy | ±1℃ | ±1℃ | ±1℃ |
Heating elements | Fe-Cr-Al-Mo wire | SiC heater | MoSi2 heater |
Furnace chamber | Imported high pure polycrystalline alumina fiber, excellent heat preservation | ||
Temperature control mode | The temperature control system uses artificial intelligence technology, with PID control, self - tuning function , 50 the heating and cooling program | ||
Heating rate | Max 50℃/min.common 20-30℃/mi | ||
Constant temperature accuracy | ±1℃ | ||
Furnace Chamber | Alumina ceramic fiber board | ||
Furnace Structure | Double shell with fan cooling | ||
Max vacuum | -0.08 MPa | ||
voltage | 110-415V 50/60Hz | ||
Package dimension | 600*670*910mm | ||
Net weight | 230kgs | ||
Gross weight | 270kgs | ||
Delivery time | 20-30 days | ||
Working temperature | Product Pictures | Heating elements | Characteristics |
W T≤1200C |
| Fe-Cr-Al-Mo wire | Compared with the ordinary iron chromium aluminum wire resistance, higher temperature and more durable |
W T≤1400C | SiC heater | Using high temperature, anti-oxidation, corrosion resistance, long life, small deformation, easy installation and maintenance. | |
W T≤1750C | MoSi2 heater | Suitable for ultra high temperature heating, long service life, high calorific value and economic price |
Selected Chamber size :
150x150x150mm 150x150x200mm
200x200x200mm 200x200x300mm or customized chamber size.
