Laboratory Test Equipment HT 1200C 1400C 1600C 1700C Tube Furnace Atmosphere Heating High Temperature Tube Furnace

1.0 Sets
MOQ
Laboratory Test Equipment HT 1200C 1400C 1600C 1700C Tube Furnace Atmosphere Heating High Temperature Tube Furnace
Features Gallery Product Description Request A Quote
Features
Specifications
Warranty: 1 Years
Classification: Laboratory Heating Equipments
Customized Support: OEM
Model Number: HT-TF01
Type: Tube Furnace
Max Temperature: 1200-1800C
Working Temperature: 1000-1700C
Temperature Control: PID Automatic Control
Heating Element: Fe-Cr-Al-Mo Wire SiC Rod MoSi2 Rod
Application: Laboratory Heating Test Equipment
Heating Rate: 0-20C/min
Basic Infomation
Model Number: HT-TF01
Payment & Shipping Terms
Packaging Details: Plastic paper inside,Polyfoam filled,Wooden box outside
Supply Ability: 100 Set/Sets per Month
Product Description

tube furnace is widely used in various reaction temperature of about 1600 ℃ of CVD experiments; also be used for vacuum sintering, vacuum sintering atmosphere protection more research, nanomaterials, battery preparation materials.

With double air-cooled structure, furnace surface temperature ≤60 ℃, furnace optional electrostatic spray, mirror stainless steel, furnace using high purity alumina ceramics fiber high temperature vacuum forming, safe and reliable, simple operation, temperature control accuracy high heating rate, effective insulation, large temperature range, furnace temperature uniformity, temperature zone more, matching the atmosphere, vacuum furnace, etc., according to customer requirements, different specifications customized tube furnace.

Features

1 Compact, portable and lightweight design.

2 Standard package includes set of stainless steel vacuum sealing flanges with valves and pressure meter.

3 Dual flanges support ensures better sealing and longer tube life.

4 Microprocessor based self-tuning PID control provides optimum thermal process with minimal overshoot.

5 Multiple atmosphere processes in a single cycle are possible (ex: binder burn out in air and parts sintering under rough vacuum or inert gas environment.)

6 Built-in ammeter and dual voltmeters for easy monitoring and troubleshooting.

7 Built-in computer interface.

8 Long life type B thermocouple.

Product Name
Laboratory Equipment Quartz Glass Gas Inlet Electric Vacuum Tube Furnace
Material
Stainless steel shell, ceramic fiber chamber
Tube
Quartz tube ,diameter 60mm, Long,300mm
Color
Blue, white, gray and as customers' requirement
Max temperature
1200.C , 1400.C, 1700.C
Temperature precision
+/- 1.C
Heat element
Electric resistance wire for 1200C, High quality silicon carbide rod for 1400C,MoSi2 heater for 1700C
Thermocouple
K type below 1200.C, S type below 1400C, B type below 1700C
Furnace structure
Double shell with air cooling fan system
Rated Power
4000W
Gas inlet
all inert gas,Nitrogen, Argon
Warrant
One year free repairing and spare parts
Standard spare parts
1 pump,1 crucible pliers, 1 resisting high temperature gloves
1 manual process instructions
Optional spare parts
Touch screen controller, Paperless recorder, Remote communication control system
Certifications
CE & ISO 9001

Note :the 1400C 1700C is also have this size too ,also we could produce according to your requirment ,we accept OEM.

Company Information

Zhengzhou Hengtong Furnace Co., Ltd. mainly produces an intelligent, programmable box furnace, a vacuum tube furnace, atmosphere furnace, dental furnace, and small industrial furnace, Furnace Hengtong in 'people-oriented' 'focused on the production of more convenient operation, the more energy Products, companies are more inclined to order-based production, according to the actual needs of customers, to design optimal solutions for customers, products more in line with customer needs, more personalized, more humane.

Expect the furnace,we also provide furnace accessories and other related products such as heating element,ceramic products ,ceramic fiber and etc .furnace

FAQ

FAQ:

Q: Are you a factory?
A: Yes. We are factory which integrates design, manufacture and sales for several years.

Q: Can I ask for customized furnace?
A: Yes, we are professional furnace manufacturer of China. We can customize according to customer's requirements.

Q: What about the delivery time?
A: Normally within 15-25 working days after receiving your payment or based on order quantity and production schedule.

Q: How can you guarantee the production quality?
A: We have several years' experience in this field. We strictly control product quality in the production process. We inspect carefully each finished product before package.

Q: Which shipment is available?
A: By sea, by air, or by express DHL TNT EMS Fedex UPS, etc. All depends on your need.

Q: What about the warranty period?
A: The warranty period is 1 years.
